Troubleshooting Guide
5-18
■iPF720 example
・ Carriage assembly
・ Pinch roller release cam
・ LF roller backup assembly
・ Pinch roller release assembly
パーマルブ G2 約24m
g
Permalub G2, about 24 mg
ベアリング
LFローラ
LFローラ
LFローラ
パーマルブ G2
約24mg
パーマルブ G2 約24mg
パーマルブ G
2 約24mg
LF roller
Bearing
Permalub G2, about 24 mg
LF roller
LF roller
Permalub G2,
about 24 mg
Permalub G2, about 24 mg
パー
マ
Permalub G2,
about 24 g
カム
:
パーマル
ブ
G2 約12g
ジョイント
:
Leaf spring:
Permalub G2, about 12 g
Cam:
Permalub G2,
about 12 g
Joints:
Molycote PG-641, about 24 g
Lock pin:
Permalub G2,
about 12 g
