Leveling Pivot Assembly

After installing the fan, check the fan is level. Use the pivot adjustment bolts to level the fan. After the fan is

level, tighten the pivot adjustment bolts. Install safety cables. Refer to Figure 22 and Figure 23.

Figure 24 - Leveling Fan

Pivot

Adjustment

Bolts

Pivot

Adjustment

Bolts

Level

Level
