INSTALLATION
It is imperative that this unit is installed and operated with the designed speed range and electrical supply
in accordance with this manual and applicable codes. If there are any questions about any items, please
call the service department at 1-866-784-6900 for warranty and technical support issues.
WARNING: TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE BRACKETS
WHEN INSTALLING THE BRACKETS, BALANCING THE BLADES, OR CLEANING THE FAN. DO
NOT INSERT FOREIGN OBJECTS IN BETWEEN ROTATING FAN BLADES.
Mechanical
WARNING: DO NOT LIFT CONTROL BY WIRING COMPONENTS. DO NOT LIFT FAN BY THE
BLADES, MOTOR SHAFT OR BEARINGS. TORQUE ALL FASTENERS PER THIS MANUAL.
Tools Required: Level, Basic wrench set, Basic socket set (up to 3/4”), Cable cutters, Lifting device or
scaffolding, Ratchet or impact gun, Torque Wrench
Main Control Enclosure Installation
The control panel enclosure must be secured to a fixed wall near the fan. Maintain adequate clearance
from excessive heat sources, such as appliances or processing equipment, to prevent damage to
the components.
There are four pre-punched holes in the backside of the control enclosure. Use suitably sized mounting
hardware to attach to the wall.
Site Preparation – Controls
• Provide clearance around installation site to safely install equipment into its final position. Supports
must adequately support equipment. Refer to manufacturer’s estimated weights.
• Consider general service and installation space when locating the control package and remote
temperature control.
• Locate the control as close to space/fan that it will serve to reduce long, unnecessary wire runs.
• Install thermostats in locations that will produce a good representation of the air being moved by the
fan in the space. Avoid thermostat installations in direct sunlight, near HVAC supplies, or abnormal
temperature air streams.
• Refer to Figure 1 on page 6 for typical control panel layout.
