HMI Menu System Overview
This chart shows the menu system of the HMI. Press the two top buttons of the HMI to enter this menu
system.
NOTE: Each HMI must have its own unique number or address. Failure to set this up correctly will
result in a Modbus communication error in the system. Press the two bottom buttons of the HMI to
access the HMI address or number.
HMI Menu Tree
NOTE: Parameters marked with an (*) are not applicable to general ventilation fans.
HMI CONFIGURATION
GROUP MODE
SET GROUP MODE
(MANUAL OR AUTO)
DEFAULT = AUTO
SELECT FAN
SELECT FAN TO
MONITOR/CONTROL
(1-10)
DEFAULT = FAN 1
ADVANCED OPTIONS
OPERATING INFO
RUNNING DATA
SHOWS SELECTED FAN
OPERATING DATA
FAN POWER (KW)
FAN CURRENT (AMPS)
FAN SPEED (HZ)
MOTOR VOLTAGE (VOLTS)
VFD LOAD (%)
TOTAL RUN TIME (HOURS)
VFD TEMPERATURE
(°F OR °C)
SENSOR ASSIGNMENTS
SHOWS ROOM TEMP
SENSOR ASSIGNMENT
TO FAN GROUPS
SENSOR 1 ASSIGNMENT
FAN ASSIGNMENTS
SHOWS FAN ASSIGNMENTS
TO FAN GROUPS
FAN 1 ASSIGNMENT
HMI SENSOR ASSIGNMENTS
SHOWS HMI SENSOR
ASSIGNMENTS
TO FAN GROUPS
HMI 1 ASSIGNMENT
FAULT HISTORY
SHOWS 10 MOST RECENT
FAULTS IN SYSTEM
ROOM
MOST RECENT FAULT
SENSOR READINGS
SHOWS ALL ROOM TEMP
SENSOR READINGS
ROOM SENSOR 1
TEMPERATURE
HMI SENSOR READINGS
SHOWS ALL HMI TEMP
SENSOR READINGS
HMI 1 TEMPERATURE
*MAINTENANCE LOG
*MAINTENANCE HISTORY
*MAINTENANCE HISTORY
EVENT TIME/DATE
*LOG MAINT. EVENT
*LOG INDIVIDULAL
MAINTENANCE ITEMS
SCHEDULING
ASSIGN OCCUPANCY
TOGGLE OCCUPANCY
SET SCHEDULE TIMES
DAY OF THE WEEK/TIME
INPUT SIMULATION
ALLOWS USER TO TEST FANS
WITH A SIMULATED INPUT
ADJUSTABLE 0-10V
SIMULATED INPUT
