NOTE: All fans assigned to a group will follow the commands from the HMI. They will all start
together, stop together, and run forward or reverse together. They will also have the same
minimum and maximum speeds and temperature limits. If independent control is needed for
specific fans, that fan should be in a group by itself.
Table 7 - Manual Mode Operation Summary
Controllable Item Range
Fan Status On/Off
Fan Speed
Min to Max
Frequency
Fan Direction (HVLS Only) Forward or Reverse
Monitoring Points Units
Power Kw
Current Amps
Speed Hz
Motor Voltage Volts
% Load %
Run Time Hours
VFD Temp °F/°C
Configurable Item Range/Limit
Min Speed 15 Hz to Max
Max Speed Min Speed to 55 Hz (HVLS)/80 Hz (Vent)
Timer Mode Auto/Off/None
Timer Setting 1 to 18 Hours
Temperature Units °F/°C
