DESCRIPTION OF THE MACHINE
2.1 TOUCH SCREEN DISPLAY ............................................ 2.2
2.1.1 Information bar .............................................................2.2
2.2 MACHINE CONFIGURATIONS ....................................... 2.3
2.3 OPTION ...........................................................................2.8
2.4 ADDITIONAL UNITS .....................................................2.12
2.5 MACHINE IDENTIFICATION .........................................2.13
2.5.1 Machine version coding logic .....................................2.14
2.6 TECHNICAL FEATURES ............................................... 2.15
2.6.1 Overall dimensions .....................................................2.16
2.6.2 Electric variants ..........................................................2.16
2.7 TRANSPORT, STORAGE AND DISPOSAL .................. 2.17
2
NOTE
The machine is modular and can be set up according to custom-
er’s requirements.
The main parts are listed below.
General description of the machine
Door lock
Fresh milk inlet
Lower
front door
Drip tray
Cup support grid
Hot water spout
Dispensing nozzles
Upper
front door
Aroma Fan
(optional)
Product containers
Touch Screen display
