Carimali BlueDotPlus - List of Electric Wirings

3.31Installation
3.5 LIST OF ELECTRIC WIRINGS
CODE DESCRIPTION QT.Y
Applicative
note
Reference to
spare tables
03.05202 Air pump wiring 1 pc. for FB only NT.05442
03.05203 Int. plug wiring General 1 pc. NT.05442
03.05204
Wiring of
switch-fuse carrier jumper
1 pc. NT.05442
03.05205 Wiring of door switch 1 pc. NT.05442
03.05206 Board power wiring 1 pc. NT.05442
03.05207
Switching
power supply wiring
1 pc. NT.05442
03.05208.rev01
Switching power
supply 24 Vdc wiring
1 pc. NT.05442
03.05209 Grinder wiring 1 pc. NT.05442
03.05210 Boiler wiring (coffee) 1 pc. NT.05442
03.05211 Base micro wiring 1 pc. NT.05442
03.05212 Presence-tray level wiring 1 pc. NT.05436
03.05213
Bonding strip
earth distributor plug
1 pc. NT.05436
03.05214 Cup sensor wiring 1 pc.
Only where the sensor
option is envisaged
NT.05433
03.05215
Magnet wiring
Cup station and aroma fan
1 pc.
Only where
the Cup Station or the
aroma fan is envisaged
NT.05433
03.05216
Presence
sensor wiring
1 pc.
Only where the
presence sensor
option is envisaged
NT.05432
03.05217 Mixer Wiring 1 pc. NT.05449
03.05218
Grinder power
resistor wiring
1 pc.
Only for countries with
240 V rated voltage
NT.05442
03.05219 Boiler bonding strips
2
pcs.
1 also for earthing of the
right metallic panel
NT.05446
03.05220
Vibration pump
wiring
1 pc. NT.05446
03.05221 6 boiler solenoid valve wiring 1 pc. NT.05446
03.05222
Wiring of temperature
cut-out jumper - boiler heating
element
1 pc. NT.05446
03.05223
3UHVVXUHÀRZPHWHU
wiring
1 pc. /
03.05224
Steam solenoid valve
wiring
1 pc.
For Fresh milk
versions only
NT.05448
03.05225
Steam exchanger
wiring
1 pc.
For Fresh milk
versions only
NT.05444
03.05226
Wiring of temperature cut-out
jumper - steam exchanger
heating element
1 pc.
For Fresh milk
versions only
NT.05444
03.05227
Steam exchanger
bonding strips
1 pc.
For Fresh milk
versions only
NT.05444
