Carimali BlueDotPlus - Air-Break; Air-Break Disassembly

4.44
Disassembly and cleaning procedures
4.12 AIR-BREAK
:DWHUVWRUDJHGHYLFHHTXLSSHGZLWKDÀRDWHULQVLGHZKLFKPRQLWRUV
the level and controls the operation of the water inlet solenoid valve
to the machine.
Remove the rear
panel through the
screws.
OFF
4.12.1 Air-Break disassembly
NOTE
Carry out this procedure only in case of replacement of the Air-
Break.
WARNING
Switch the
machine off.
Air-Break
