4.2
Disassembly and cleaning procedures
4.1 SERVICE MODE
4.2 DISCONNECTION OF ELECTRIC WIRING
ATTENTION
The SERVICE mode can be accessed with the cut-off key of the
door safety micro-switch.
Be very careful during the maintenance phases when the door is
open and the voltage is energised.
ATTENTION
'R QRW GDPDJH WKH HOHFWULF FRQQHFWLRQV 3UHVV WKH ORFNLQJ ÀDS
before removing the connector to prevent it being damaged.
4.3 DISCONNECTION OF HYDRAULIC HOSE LINES
3UHVVWKH ÀDQJH WR-
wards the joint to re-
lease the hose.
5HPRYH WKH 7HÀRQ
hose.
1 2
1
1
1
1
2
2
2
/RFNLQJÀDS
/RFNLQJÀDS
Joint
Flange
7HÀRQKRVH
