4.4
Disassembly and cleaning procedures
4.5 COFFEE / INSTANT PRODUCTS CONTAINERS
4.5.1 Disassembly of coffee/instant products containers
Open the upper
front door.
Remove the instant
product containers
from the machine.
3UHVV WKH ÀDS WR
close the side.
Remove the coffee
containers from the
machine.
NOTE
The procedures described in this paragraph apply both to standard
containers and to raised ones (optional).
NOTE
Procedure for cof-
fee containers only.
NOTE
Procedure for in-
stant products con-
tainers only.
1
2
1
2
View from the bottom up
Description end
