Carimali BlueDotPlus - Additional Board 2 Nd Group (Code 96.05292); Dispensing Compartment Electronic Wiring (Code 96.05351); Logo Lighting Board (Code 96.05353)

3.26
Installation
3.4.6 Additional board 2nd group (Code 96.05292)
In the version “EF” (Espresso + Fresh Brew), the 2nd group addi-
tional board powers the Fresh Brew group.
3.4.7 Logo lighting board (Code 96.05353)
The logo lighting board powers the CARIMALI logo LED.
3.4.8 Dispensing compartment electronic wiring (Code 96.05351)
The dispensing compartment wiring enables lighting of the compart-
ment itself.
From
Fresh Brew group
