Carimali BlueDotPlus - Version Espresso + Fresh Brew (EF + 1 M); Version Espresso + Fresh Brew

3.36
Installation
3.6.3 Version Espresso + Fresh Brew (EF + 1M)
Milk Cold water Hot water Steam Air
NParts
1 Water stop solenoid valve 2 Air break 3 Vibration pump 4 4-way valve + VNR 5 Flowmeter 6 Coffee/instant product boiler
NParts
7 Espresso 3-way solenoid valve 8 Espresso group 9
2-way, 2-element solenoid valve block
10 Decanter Fresh Brew
11 Steam 3-way solenoid valve
N Parts
12 Steam boiler 13 Milker steam solenoid valve 14
Milker rinsing water solenoid valve
15
Air 2-way solenoid valve block Milker/rinsing
NParts
16 Milk frother 17 Air pump 18 Check valve 19 Fresh Brew unit 20 Water tank
9
19
10
8
16
6
4
3
7
12
11
15
14 13
2
1
5
17
18
20
