3.16
Installation
3.2 JOLLY VERSION (WT+WM)
3.2.1 Passage from the water mains (WM) to the tank (WT)
The Jolly version can operate with the water mains connection or
with the tank. It is possible to switch from a version to the other fol-
lowing the procedures below.
The following image
shows the situa-
tion when the water
mains connection is
enabled.
Position a container
for collecting water
and disconnect the
connection hose of
the air break to the
ÀRZPHWHU
Discharge water in
the air break into the
container.
Take the tank hose.
Flowmeter
Air break hose
