3.32
Installation
CODE DESCRIPTION QT.Y
Applicative
note
Reference to
spare tables
03.05228 Espresso group wiring 1 pc.
For espresso
machines only
NT.05439
03.05229 Fresh Brew group wiring 1 pc.
Fresh-Brew
machines only
NT.05442
03.05230
Left Fresh Brew group
wiring
1 pc.
Dual group machines only NT.05442
03.05231.rev01 RFiD board wiring 1 pc.
Only machines with
RFID option
NT.05432
03.05232
Espresso group
encoder wiring
1 pc. /
03.05233
Espresso group
gear motor wiring
1 pc. /
03.05234 Logo lightening LED wiring 1 pc. NT.05432
03.05235
Base micro
wiring for dual group machine
1 pc. /
03.05236.rev02 Doser motor protection wiring
2
pcs.
In series with
the motor wiring
NT.05449
03.05241 Flowmeter wiring 1 pc.
Alternative to 03.05223 NT.05446
03.05242 :LUHG¿OWHUFDSDFLWRU 1 pc. NT.05442
03.05247.rev02
3rd doser wiring with motor
protection
1 pc.
Only machines with
3rd instant product
NT.05452
03.05248
Flat door presence sensor
wiring
1 pc.
)RUPDFKLQHVZLWKÀDW
door only
/
03.05249
GSM modem 300 mm
cable wiring
1 pc.
For machines with
Modem GSM GEMALTO
option only
/
03.05250
GSM modem 1250 mm
cable wiring
1 pc.
For machines with Modem
GSM GEMALTO option
(external assembly) only
NT.05456
03.05251.rev01 ES compactor wiring 1 pc.
Standard for the newly
produced machines
(Standard ES version)
NT.05461
03.05258 MDB interface cable wiring 1 pc.
For machines with MDB
interface option only
/
03.05259.rev01
Wiring of compactor
ES + 3 sol
1 pc.
Standard for the newly
produced machines
(ES version with 3rd in-
stant product)
NT.05461
03.05260.rev01
Air pump wiring
and compactor ES
1 pc.
Standard for the newly
produced machines
(ES + FB version)
NT.05461
03.05261.rev01
Air pump wiring
FB + 3 instant products
1 pc.
For FB machines with 3rd
instant product only
NT.05452
03.05266
MDB token box
power supply wiring
1 pc.
With Cash or Cashless
devices only
NT.05468
03.05285
MDB external power supply
adapter wiring
1 pc.
With Cash or Cashless
devices only
03.05286
Wiring of vibration pump
and third grinder
1 pc.
For standard machine
with 3rd grinder only
