3.33Installation
CODE DESCRIPTION QT.Y
Applicative
note
Reference to
spare tables
03.05287
Diode bridge wiring -
third grinder
1 pc.
For standard machine
with 3rd grinder only
03.05288 Milk pump board wiring 1 pc.
Wiring by the
fridge supplier
/
03.05289
Milk pump board 24V power
supply wiring
1 pc.
Wiring by the
fridge supplier
/
03.05290 Milk pump board signal wiring 1 pc.
Wiring by the
fridge supplier
/
96.05351.01
Flat door dispensing
compartment LED wiring
2
pcs.
,QLWLDOO\IRUÀDWGRRU
subject to availability as
replacement of the
current code 00
/
96.05389.CA
Wired 30x30 5Vdc exhaust
unit
1 pc.
For machine with voltage
100 and 110 V only
NT.05442
96.05076.L3
Cup Station door presence
sensor
1 pc.
Only where
the Cup Station option is
envisaged
NT.05433
96.05076.L4 Decaf door presence sensor 1 pc.
Only where the Decaf
option is envisaged
/
96.05334.CA
Wired 60x60x25 machine
exhaust unit
1 pc. NT.05442
96.05335.CA
Wired 60x60x25 instant
product exhaust unit
1 pc. NT.05442
96.05341 Ethernet Emerson cable 1 pc. NT.05442
96.05349.CA Wired 40x40x20 exhaust unit 1 pc.
Only where the Aroma fan
option is envisaged
NT.05432
96.05350.L1 Safety wiring coffee 1 1 pc. NT.05434
96.05350.L2 Safety wiring coffee 2 1 pc.
Only where the second
grinder is envisaged
NT.05434
96.05350.L3 Safety wiring instant product 1 1 pc.
Only if the instant
products are present
NT.05437
96.05350.L4 Safety wiring instant product 2 1 pc.
Only if the instant
products are present
NT.05437
96.05350.L5 Tank level reed 1 pc.
Only where the tank
is envisaged
NT.05437
96.05351.rev01
Dispensing compartment LED
wiring
2
pcs.
NT.05432
WARNING
For further information, refer to the relevant Spare part catalogue.
(Table ELECTRICAL MODULE - NT.05442).
NOTE
For further information, refer to the Carimali Service Centre and
WKHUHOHYDQW6SDUH3DUWV&DWDORJXHIRUWKHODWHVWPRGL¿FDWLRQ
