2.4
Description of the machine
Version Espresso “E” + instant products
(Tank or water connection or Jolly)
Version Fresh Brew “F” + instant products
(tank or water connection or Jolly)
1 2 1
Coffee bean
containers
Coffee grinder
Fresh Brew group
Grounds drawer
Instant product
container
Milker
Instant product
container
Mixer 2
Mixer 1
Water tank
Coffee bean
containers
Coffee bean
containers
Coffee grinder
Espresso group
Grounds drawer
Instant product
container
Milker
Instant product
container
Mixer 2
Mixer 1
Water tank
1 2 2 1
