Table 28 — Motor and Drive Package Data, Airfoil Fan
UNIT
SIZE
MOTOR
FRAME
FAN DISCHARGE
THF/THR UBF/UBR
Centerline Distance (in.)
Min Max Min Max
07
143T 7.4 9.5 9.5 11.1
145T 7.4 9.5 9.5 11.1
182T 6.1 8.3 8.1 9.7
184T 6.1 8.3 8.1 9.7
213T 5.5 7.7 7.4 8.9
09
145T 10.2 12.2 12.8 14.3
182T 8.8 11.0 11.4 12.9
184T 8.8 11.0 11.4 12.9
213T 8.1 10.3 10.5 12.1
215T 8.1 10.3 10.5 12.1
11
145T 10.3 12.2 12.6 14.1
182T 8.5 10.5 10.8 12.3
184T 8.5 10.5 10.8 12.3
213T 7.7 9.9 9.9 11.5
215T 7.7 9.9 9.9 11.5
254T 6.7 8.9 8.7 10.3
13
145T 11.6 13.9 14.8 16.3
182T 10.8 13.1 13.8 15.4
184T 10.8 13.1 13.8 15.4
213T 9.8 12.4 12.9 14.5
215T 9.8 12.4 12.9 14.5
254T 8.9 11.5 11.7 13.4
256T 8.9 11.5 11.7 13.4
17
145T 10.3 12.2 12.6 14.1
182T 13.4 15.7 16.8 18.4
184T 13.4 15.7 16.8 18.4
213T 12.6 15.0 15.9 17.5
215T 12.6 15.0 15.9 17.5
254T 11.5 14.0 14.7 16.3
256T 11.5 14.0 14.7 16.3
21
182T 15.7 17.6 19.3 21.3
184T 15.7 17.6 19.3 21.3
213T 15.7 17.7 19.1 20.6
215T 15.7 17.7 19.1 20.6
254T 14.5 16.6 17.8 19.4
256T 14.5 16.6 17.8 19.4
284T 13.6 15.8 16.9 18.6
286T 13.6 15.8 16.9 18.6
26
182T 18.5 20.4 22.5 23.9
184T 18.5 20.4 22.5 23.9
213T 18.5 20.5 22.2 23.8
215T 18.5 20.5 22.2 23.8
254T 17.3 19.3 21.0 22.5
256T 17.3 19.3 21.0 22.5
284T 16.4 18.6 20.1 21.7
286T 16.4 18.6 20.1 21.7
32
184T 14.4 17.1 19.0 21.0
213T 13.9 16.8 18.5 20.5
215T 13.9 16.8 18.5 20.5
254T 13.3 16.4 17.7 19.7
256T 13.3 16.4 17.7 19.7
284T 13.0 16.1 17.2 19.2
286T 13.0 16.1 17.2 19.2
324T 12.4 15.8 16.4 18.6
326T 12.4 15.8 16.4 18.6
UNIT
SIZE
MOTOR
FRAME
FAN DISCHARGE
THF/THR UBF/UBR
Centerline Distance (in.)
Min Max Min Max
39
213T 16.2 18.9 21.0 23.0
215T 16.2 18.9 21.0 23.0
254T 15.5 18.4 20.3 22.3
256T 15.5 18.4 20.3 22.3
284T 15.1 18.1 19.7 21.7
286T 15.1 18.1 19.7 21.7
324T 14.5 17.7 19.0 21.0
326T 14.5 17.7 19.0 21.0
364T 14.0 17.3 18.2 20.4
49
215T 21.0 23.8 26.2 28.2
254T 20.5 23.3 25.4 27.3
256T 20.5 23.3 25.4 27.3
284T 20.0 23.0 24.8 26.8
286T 20.0 23.0 24.8 26.8
324T 19.5 22.5 24.0 26.3
326T 19.5 22.5 24.0 26.3
364T 19.0 22.1 23.4 25.6
365T 19.0 22.1 23.4 25.6
61
215T 25.9 28.5 32.0 34.0
254T 25.3 28.0 31.0 33.1
256T 25.3 28.0 31.0 33.1
284T 24.9 27.7 30.7 32.7
286T 24.9 27.7 30.7 32.7
324T 24.3 27.2 29.9 32.0
326T 24.3 27.2 29.9 32.0
364T 23.7 26.8 29.2 31.3
365T 23.7 26.8 29.2 31.3
404T 23.2 26.3 28.5 30.7
74
256T 24.0 28.7 30.0 33.5
284T 23.5 28.4 29.4 33.1
286T 23.5 28.4 29.4 33.1
324T 22.9 27.9 28.7 32.4
326T 22.9 27.9 28.7 32.4
364T 22.3 27.5 27.9 31.8
365T 22.3 27.5 27.9 31.8
404T 21.8 27.1 27.1 31.2
405T 21.8 27.1 27.1 31.2
92
256T 33.6 40.5 43.5 48.5
284T 33.2 40.1 42.9 48.0
286T 33.2 40.1 42.9 48.0
324T 32.6 39.7 42.1 47.4
326T 32.6 39.7 42.1 47.4
364T 32.1 39.3 41.3 46.7
365T 32.1 39.3 41.3 46.7
404T 31.5 38.9 40.6 46.1
405T 31.5 38.9 40.6 46.1
LEGEND
THF — Top Horizontal Front
THR — Top Horizontal Rear
UBF — Upblast Front
UBR — Upblast Rear
NOTE: Variable-speed drives are not available for motors of 20 Hp or
greater.
