Table 14 — Component Weights (Lb) (Single-Wall Casing)*
SECTION
TYPE
COMPONENT†
39T UNIT SIZE
07 09 11 13 17 21 26
FAN
AFS3 375 500 625 775 925 1050 1300
AFS4 375 500 625 775 925 1050 1300
AFS5 375 500 625 775 925 1050 1300
FCS3 325 550 575 725 875 1000 1350
FCS4 325 550 575 725 875 1000 1350
FCS5 325 550 575 725 875 1000 1350
PAF3 — — 710 900 1025 1160 1415
PAF5 — — 710 900 1025 1160 1415
RAF2 375 500 625 775 925 1050 1300
RFC2 325 550 575 725 875 1000 1350
COIL
LCS1 80 120 160 200 240 280 540
MCS1 80 120 160 200 240 280 340
MHS1 50 60 70 90 110 130 160
VCS1 175 250 300 375 450 525 600
VCS2 — — — 413 495 578 660
VCS3 — — — 413 495 578 660
BPH1 145 163 185 200 220 245 270
BCC2 80 120 160 200 240 280 540
EHS1 154 168 190 204 226 260 306
BCS1 380 450 520 600 690 790 900
BCS2 380 450 520 600 690 790 900
BCS3 260 310 350 390 450 550 650
BCS4 260 310 350 390 450 550 650
BCS7 220 270 305 340 400 490 595
DAMPER
ZDS1 125 140 155 173 190 205 225
FBH1 263 313 361 412 470 543 610
FBH2 346 396 444 495 553 626 693
FBC1 198 270 336 412 490 578 880
EXB1 150 180 200 240 365 395 425
EXB2 150 180 200 240 365 395 425
AIR MIXER AMX1 220 233 252 360 392 422 448
MIXING BOX
MXB1 160 190 230 275 400 450 500
MXB5 160 190 230 275 400 450 500
MXB6 160 190 230 275 400 450 500
MXB7 160 190 230 275 400 450 500
FILTER MIXING BOX
FMB1 300 330 380 425 575 625 675
FMB2 300 330 380 425 575 625 675
FMB3 300 330 380 425 575 625 675
FMB4 300 330 380 425 575 625 675
ACCESS
ACC1 67 75 83 91 99 107 115
ACC2 84 94 104 114 124 134 144
FILTER
ANG1 125 148 170 194 212 233 254
BCF1 138 154 170 188 210 250 304
BCF3 327 368 415 472 523 560 614
FLT1 94 102 118 130 142 154 166
*For double-wall casing, multiply by 1.25.
†For complete component definition, see Table 1.
NOTES:
1. Coil section weights are without coil. See Table 15, page 27, for dry coil weights.
2. Fan section weights are without motors and drives. See Table 13, page 24, for motor weights.
3. Filter section weights are without filters. Filters are not shipped with the unit.
25
