Carrier 39T User Manual

Table 29 — Motor and Drive Package Data, Plenum Fan
UNIT
SIZE
MOTOR
FRAME
FAN WHEEL
Small Standard
Centerline Distance (in.)
Min Max Min Max
11
143T — — 20.6 23.6
145T — — 20.6 23.6
182T — — 20.5 23.4
184T — — 20.5 23.4
213T — — 20.1 23.6
215T — — 20.1 23.6
254T — — 19.9 23.9
13
143T — — 22.2 25.2
145T — — 22.2 25.2
182T — — 22.1 25.0
184T — — 22.1 25.0
213T — — 21.7 25.2
215T — — 21.7 25.2
254T — — 21.4 25.4
256T — — 21.4 25.4
17
145T — — 25.2 28.1
182T — — 24.0 27.8
184T — — 24.9 27.8
213T — — 24.5 27.9
215T — — 24.5 27.9
254T — — 24.0 28.0
256T — — 24.0 28.0
284T — — 23.7 28.2
21
145T 26.5 29.4 28.4 31.3
182T 26.1 29.1 28.1 31.0
184T 26.1 29.1 28.1 31.0
213T 25.7 29.1 27.6 31.0
215T 25.7 29.1 27.6 31.0
254T 25.2 29.2 27.1 31.1
256T 25.2 29.2 27.1 31.1
284T 24.8 29.3 26.8 31.2
286T — — 26.8 31.2
26
145T 28.4 31.3 32.2 35.1
182T 28.1 31.0 31.9 34.8
184T 28.1 31.0 31.9 34.8
213T 27.6 31.0 31.4 34.8
215T 27.6 31.0 31.4 34.8
254T 27.1 31.1 31.0 34.9
256T 27.1 31.1 31.0 34.9
284T 26.8 31.2 30.6 35.0
286T 26.8 31.2 30.6 35.0
324T — — 30.0 35.2
32
145T 28.4 31.3 32.2 35.1
182T 28.1 31.0 31.9 34.8
184T 28.1 31.0 31.9 34.8
213T 27.6 31.0 31.4 34.8
215T 27.6 31.0 31.4 34.8
254T 27.1 31.1 31.0 34.9
256T 27.1 31.1 31.0 34.9
284T 26.8 31.2 30.6 35.0
286T 26.8 31.2 30.6 35.0
324T — — 30.0 35.2
39
145T 34.7 37.6 37.6 40.4
182T 34.3 37.2 37.1 40.0
184T 34.3 37.2 37.1 40.0
213T 33.8 37.2 36.6 40.0
215T 33.8 37.2 36.6 40.0
254T 33.2 37.2 36.0 39.9
256T 33.2 37.2 36.0 39.9
284T 32.8 37.3 35.6 40.0
286T 32.8 37.3 35.6 40.0
324T 32.2 37.4 34.9 40.1
326T 32.2 37.4 34.9 40.1
UNIT
SIZE
MOTOR
FRAME
FAN WHEEL
Small Standard
Centerline Distance (in.)
Min Max Min Max
49
145T 37.6 40.4 42.1 44.9
182T 37.1 40.0 41.6 44.4
184T 37.1 40.0 41.6 44.4
213T 36.6 40.0 41.0 44.4
215T 36.6 40.0 41.0 44.4
254T 36.0 40.0 40.4 44.3
256T 36.0 40.0 40.4 44.3
284T 35.6 40.0 40.0 44.3
286T 35.6 40.0 40.0 44.3
324T 34.9 40.1 39.2 44.4
326T 34.9 40.1 39.2 44.4
364T — — 38.6 44.5
61
182T 41.6 44.4 45.6 48.3
184T 41.6 44.4 45.6 48.3
213T 41.0 44.4 44.9 48.2
215T 41.0 44.4 44.9 48.2
254T 40.4 44.3 44.2 48.0
256T 40.4 44.3 44.2 48.0
284T 40.0 44.3 43.7 48.0
286T 40.0 44.3 43.7 48.0
324T 39.2 44.4 42.9 48.0
326T 39.2 44.4 42.9 48.0
364T 38.6 44.5 42.3 48.1
365T — — 42.3 48.1
74
213T 47.3 50.6 50.3 53.5
215T 47.3 50.6 50.3 53.5
254T 46.6 50.4 49.6 53.3
256T 46.6 50.4 49.6 53.3
284T 46.1 50.4 49.1 53.3
286T 46.1 50.4 49.1 53.3
324T 45.3 50.3 48.2 53.2
326T 45.3 50.3 48.2 53.2
364T 44.6 50.5 47.6 53.3
365T 44.6 50.5 47.6 53.3
404T 43.8 50.7 46.7 53.4
405T 43.8 50.7 46.7 53.4
92
213T 55.2 58.4 60.6 63.8
215T 55.2 58.4 60.6 63.8
254T 54.5 58.2 59.9 63.5
256T 54.5 58.2 59.9 63.5
284T 54.0 58.1 59.3 63.5
286T 54.0 58.1 59.3 63.5
324T 53.1 58.0 58.4 63.3
326T 53.1 58.0 58.4 63.3
364T 52.4 58.0 57.7 63.3
365T 52.4 58.0 57.7 63.3
404T 51.4 58.1 56.7 63.3
405T 51.4 58.1 56.7 63.3
NOTES:
1. Small fan wheel not available for sizes 11-17.
2. Variable-speed drives are not available for motors of 20 Hp or greater.
101
