Table 1 — Component Description
39T (Horizontal) and (Vertical)
Unit Components
COMPONENT DESCRIPTION
UNIT SIZE
AVAILABILITY
ACC1 Access (upstream location) 07-92
AFS3
Airfoil Fan, Horizontal
Draw-Thru
07-92
AFS4
Airfoil Fan, Vertical
Draw-Thru
07-92
AFS5 Airfoil Fan, Blow-Thru 07-92
AMX1 Air Mixer 07-92
ANG1 Angle Filter 07-92
BCC2
Bypass Cooling Coil
(no damper)
B 07-92
BCF1
Bag/Cartridge Filter
(upstream location, 2-in.
prefilters)
07-92
BPH1
Bypass Heating Coil
(no damper)
B 07-92
EHS1 Electric Heating Coil M 07-92
FBC1
Bypass Cooling Coil (with
damper)
B 07-92 (*as is)
FBH1
Bypass Heating Coil (with
damper)
B 07-92 (*as is)
FBH2
Bypass Heating Coil
(extended length with
damper)
B 07-92
FCS3
Forward-Curved Fan
(horizontal draw-thru)
07-61
FCS4
Forward-Curved Fan
(vertical draw-thru)
07-61
FCS5
Forward-Curved Fan
(blow-thru)
07-61
FLT1 Flat Filter 07-92
FMB1
Combination Filter Mixing Box
(top and rear inlet, standard
dampers)
07-92
FMB2
Combination Filter Mixing Box
(bottom and rear inlet, stand-
ard dampers)
07-92
FMB3
Combination Filter Mixing Box
(top and rear inlet, premium
dampers)
07-92
FMB4
Combination Filter Mixing Box
(bottom and rear inlet, pre-
mium dampers)
07-92
LCS1 Large Cooling Coil L 07-92
MCS1 Medium Cooling Coil M 07-92
MHS1 Medium Heating Coil L 07-26 M 32-92
MXB1
Mixing Box (top and rear
inlet, standard dampers)
07-92
MXB5
Mixing Box (top and rear
inlet, for use with EXB1,
standard dampers)
07-92
MXB6
Mixing Box (top and rear
inlet, premium dampers)
07-92
MXB7
Mixing Box (top and rear
inlet, for use with EXB2, pre-
mium dampers)
07-92
PAF3 Plenum Fan (draw-thru) 11-92
VCS1 Vertical Cooling Coil L 07-61
VCS2 Vertical Cooling/Heating Coil L 13-26 M 32-61
VCS3 Vertical Heating/Cooling Coil L 13-26 M 32-61
39T Return Fan Components
COMPONENT DESCRIPTION
UNIT SIZE
AVAILABILITY
EXB1
Exhaust Box (standard
dampers)
07-92
EXB2
Exhaust Box (premium
dampers)
07-92
RAF2 Return-Air Airfoil Fan 07-92
RFC2
Return-Air Forward-Curved
Fan
07-61
39T Blow-Thru Components
COMPONENT DESCRIPTION
UNIT SIZE
AVAILABILITY
BCF3
Bag/Cartridge Filter
(downstream location, 2-in.
prefilters)
07-92
BCS1
Blow-Thru Cooling/Heating
Coil (front discharge)
L/S 07-26
M/S 32-92
BCS2
Blow-Thru Cooling/Heating
Coil (top discharge)
L/S 07-26
M/S 32-92
BCS3
Blow-Thru Cooling Coil
(front discharge)
L 07-26
M 32-92
BCS4
Blow-Thru Cooling Coil
(top discharge)
L 07-26
M 32-92
BCS7
Blow-Thru Cooling Coil (full
front discharge, downstream
components)
L 07-26
M 32-92
ACC2 Access 07-92
PAF5 Plenum Fan (blow-thru) 11-92
ZDS1 Zone Damper 07-92
LEGEND
B—Bypass Coils
L—Large Face Area
M—Medium Face Area
S—Small Face Area
*Accommodates bypass size chilled water coil. No bypass size direct
expansion coils are available.
NOTES:
1. First coil type is upstream coil, cold deck coil in BCS1 or 2.
2. Second coil type is downstream, hot deck coil in BCS1 or 2.
3. Coil sections may be ordered less coils.
4. First coil/second coil type.
