Table 27 — Motor and Drive Package Data, Forward-Curved Fans
UNIT
SIZE
MOTOR
FRAME
FAN DISCHARGE
THF/THR UBF/UBR
Centerline Distance (in.)
Min Max Min Max
07
143T 7.4 9.0 9.5 11.1
145T 7.4 9.0 9.5 11.1
182T 6.1 7.8 8.1 9.7
184T 6.1 7.8 8.1 9.7
213T 5.5 7.2 7.4 8.9
09
145T 10.1 12.1 12.8 14.3
182T 8.8 11.0 11.4 12.9
184T 8.8 11.0 11.4 12.9
213T 8.1 10.3 10.5 12.1
215T 8.1 10.3 10.5 12.1
11
145T 10.4 12.4 13.0 14.5
182T 8.6 10.7 11.2 12.7
184T 8.6 10.7 11.2 12.7
213T 7.9 10.1 10.3 11.9
215T 7.9 10.1 10.3 11.9
254T 6.9 9.1 9.1 10.7
13
145T 11.6 13.9 14.8 16.3
182T 10.8 13.1 13.8 15.4
184T 10.8 13.1 13.8 15.4
213T 9.8 12.4 12.9 14.5
215T 9.8 12.4 12.9 14.5
254T 8.9 11.5 11.7 13.4
17
145T 7.4 9.0 9.5 11.1
182T 13.4 15.7 16.8 18.4
184T 13.4 15.7 16.8 18.4
213T 12.6 15.0 15.9 17.5
215T 12.6 15.0 15.9 17.5
254T 11.5 14.0 14.7 16.3
256T 11.5 14.0 14.7 16.3
21
145T 7.4 9.0 9.5 11.1
182T 15.7 17.6 19.2 20.7
184T 15.7 17.6 19.2 20.7
213T 15.6 17.6 19.0 20.5
215T 15.6 17.6 19.0 20.5
254T 14.5 16.5 17.7 19.3
256T 14.5 16.5 17.7 19.3
284T 13.6 15.8 16.8 18.5
26
182T 18.5 20.3 22.2 23.6
184T 18.5 20.3 22.2 23.6
213T 18.4 20.4 22.0 23.5
215T 18.4 20.4 22.0 23.5
254T 17.2 19.3 20.7 22.3
256T 17.2 19.3 20.7 22.3
284T 16.4 18.5 19.8 21.4
UNIT
SIZE
MOTOR
FRAME
FAN DISCHARGE
THF/THR UBF/UBR
Centerline Distance (in.)
Min Max Min Max
32
184T 14.4 17.2 19.3 21.3
213T 14.0 16.9 18.7 20.7
215T 14.0 16.9 18.7 20.7
254T 13.4 16.5 18.1 20.1
256T 13.4 16.5 18.1 20.1
284T 13.0 16.2 17.5 19.5
286T 13.0 16.2 17.5 19.5
324T 12.5 15.9 16.7 18.9
39
213T 16.2 19.0 21.4 23.4
215T 16.2 19.0 21.4 23.4
254T 15.6 18.5 20.6 22.6
256T 15.6 18.5 20.6 22.6
284T 15.2 18.2 20.0 22.0
286T 15.2 18.2 20.0 22.0
324T 14.6 17.8 19.3 21.4
326T 14.6 17.8 19.3 21.4
49
213T 21.2 24.2 27.5 29.5
215T 21.2 24.2 27.5 29.5
254T 20.7 23.7 26.7 28.7
256T 20.7 23.7 26.7 28.7
284T 20.3 23.4 26.1 28.2
286T 20.3 23.4 26.1 28.2
324T 19.8 23.0 25.4 27.5
326T 19.8 23.0 25.4 27.5
61
213T 26.0 28.8 32.7 34.7
215T 26.0 28.8 32.7 34.7
254T 25.4 28.3 32.0 34.0
256T 25.4 28.3 32.0 34.0
284T 25.0 27.9 31.5 33.5
286T 25.0 27.9 31.5 33.5
324T 24.5 27.5 30.7 32.7
326T 24.5 27.5 30.7 32.7
LEGEND
THF — Top Horizontal Front
THR — Top Horizontal Rear
UBF — Upblast Front
UBR — Upblast Rear
NOTE: Variable-speed drives are not available for motors of 20 Hp or
greater.
99
