Table 14 — Component Weights (Lb) (Single-Wall Casing)* (cont)
SECTION
TYPE
COMPONENT†
39T UNIT SIZE
32 39 49 61 74 92
FAN
AFS3 1776 1957 2415 2840 3304 3880
AFS4 1776 1957 2415 2840 3304 3880
AFS5 1776 1957 2415 2840 3304 3880
FCS3 1654 1825 2180 2479 — —
FCS4 1654 1825 2180 2479 — —
FCS5 1654 1825 2180 2479 — —
PAF3 1900 2090 2555 2995 3475 4055
PAF5 1900 2090 2555 2995 3475 4055
RAF2 1776 1957 2415 2840 3304 3880
RFC2 1654 1825 2180 2479 — —
COIL
LCS1 577 651 754 876 995 1210
MCS1 383 422 487 592 649 730
MHS1 340 378 440 514 586 665
VCS1 677 775 965 1160 — —
VCS2 745 853 1062 1276 — —
VCS3 745 853 1062 1276 — —
BPH1 340 378 440 514 586 665
BCC2 577 651 754 876 995 1210
EHS1 354 402 466 542 616 697
BCS1 1022 1160 1434 1719 1965 2406
BCS2 1022 1160 1434 1719 1965 2406
BCS3 753 853 1074 1288 1483 1845
BCS4 753 853 1074 1288 1483 1845
BCS7 671 759 952 1131 1308 1634
DAMPER
ZDS1 241 266 333 366 452 452
FBH1 720 806 930 1108 1252 1410
FBH2 805 895 1027 1215 1369 1535
FBC1 957 1099 1244 1470 1661 1955
EXB1 498 622 700 862 1010 1110
EXB2 498 622 700 862 1010 1110
AIR MIXER AMX1 568 629 680 883 1172 1217
MIXING BOX
MXB1 574 712 814 1002 1178 1310
MXB5 574 712 814 1002 1178 1310
MXB6 574 712 814 1002 1178 1310
MXB7 574 712 814 1002 1178 1310
FILTER MIXING BOX
FMB1 775 910 1014 1200 1377 1510
FMB2 775 910 1014 1200 1377 1510
FMB3 775 910 1014 1200 1377 1510
FMB4 775 910 1014 1200 1377 1510
ACCESS
ACC1 123 130 139 152 166 174
ACC2 154 163 174 190 207 218
FILTER
ANG1 273 292 325 365 393 432
BCF1 354 402 466 542 613 698
BCF3 667 728 807 916 1018 1127
FLT1 178 192 220 255 281 314
*For double-wall casing, multiply by 1.25.
†For complete component definition, see Table 1.
NOTES:
1. Coil section weights are without coil. See Table 15, page 27, for dry coil weights.
2. Fan section weights are without motors and drives. See Table 13, page 24, for motor weights.
3. Filter section weights are without filters. Filters are not shipped with the unit.
26
