Table 22 — Electric Heater Data, Horizontal Heaters Used in EHS1 (cont)
39T
UNIT SIZE
HEATER
AREA
(Sq Ft)
NO. OF
CONTROL
STEPS
HEATER
COIL
kW
TEMP
RISE
(°F)
MIN COIL
FACE VEL
(Fpm)
POWER SUPPLY, 3-PHASE CIRCUITS
480 Volts 600 Volts
Total FLA No. Sub-Ckts MWG Fuse Total FLA No. Sub-Ckts MWG Fuse
32 24.0
3 39 32 160 47 1 6 60 38 1 6 50
6
79 40 260 96 2 1 125 76 2 3 100
119 51 310 144 3 3/0 200 115 3 1/0 150
133 50 350 160 4 3/0 200 128 3 2/0 175
8
166 60 370 200 5 250 250 160 4 3/0 200
199 62 425 240 5 350 300 192 4 250 250
239 67 475 288 6 500 400 230 8 350 300
279 71 525 336 7 (2)250 500 269 8 400 350
39 28.8
3 66 35 210 80 2 3 100 64 2 4 80
6
99 42 260 120 3 1/0 150 95 2 1 125
133 48 310 160 4 3/0 200 128 3 2/0 175
159 50 350 192 4 250 250 153 6 3/0 200
8
199 60 370 240 5 350 300 192 4 250 250
232 61 420 280 6 500 350 224 8 300 300
299 68 490 360 8 (2)300 500 288 8 500 400
332 70 525 400 9 (2)350 500 320 8 (2)250 400
49 38.1
3 79 32 210 96 2 1 125 76 3 3 100
6
99 38 220 120 3 1/0 150 95 2 1 125
133 43 260 160 4 3/0 200 128 3 2/0 175
159 43 310 192 4 250 250 153 6 3/0 200
199 48 350 240 5 350 300 192 6 250 250
8
299 60 420 360 8 (2)300 500 288 8 500 400
359 65 460 432 9 (2)400 600 346 8 (2)300 500
432 70 515 520 11 (3)300 700 416 9(U)* (2)400 600
61 48.8
3 79 32 160 96 2 1 125 76 3 3 100
6
119 37 210 144 3 3/0 200 115 3 1/0 150
133 40 220 160 4 3/0 200 128 3 2/0 175
159 40 260 192 4 250 250 153 6 3/0 200
199 42 310 240 5 350 300 192 6 250 250
239 37 420 288 6 500 400 230 6 350 300
8
359 61 425 480 10 (5)500 600 384 8 (2)350 500
498 50 650 600 13 (3)400 800 480 10 (2)500 600
74 59.1
3 79 27 160 96 2 1 125 76 2 3 100
6
119 31 210 144 3 3/0 200 115 3 1/0 150
133 33 220 160 4 3/0 200 128 3 2/0 175
159 37 230 192 4 250 250 153 6 3/0 200
199 41 260 240 5 350 300 192 6 250 250
8
299 46 350 360 8 (2)300 500 288 6 500 400
399 58 370 480 10 (2)500 600 384 8 (2)350 500
465 60 420 560 12 (3)350 700 448 10(U)* (2)500 600
92 73.0
6
133 36 160 160 4 3/0 200 128 3 2/0 175
166 33 220 200 5 250 250 160 6 3/0 200
199 38 230 240 5 350 300 192 6 250 250
266 45 260 320 7 (2)250 400 256 6 400 350
8
332 47 310 400 9 (2)350 500 320 7 (2)250 400
518 54 420 624 13 (3)500 800 499 11(U)* (2)500 700
565 57 430 680 15 (3)500 1000 544 12(U)* (3)350 700
678 64 460 816 17 (4)400 1200 653 14(U)* (3)500 1000
LEGEND
ARI — Air Conditioning & Refrigeration Institute
FLA — Total Full Load Amps of Electric Heating Coils
Fuse — External Fuse Size Required Per Circuit
kW — Kilowatt Rating
MWG — Minimum Wire Gage
VEL — Velocity
*(U) signifies unequal kW per step.
NOTES:
1. Subcircuits are internal heater circuits of 48 A or less ampacity.
2. Minimum wire gage is based on 75 C copper conductors; 3 conductors per
circuit.
IMPORTANT: To avoid damage from overheating, coils must not be
operated at less than minimum airflow (cfm).
Minimum Cfm = Coil Face Area x Minimum Coil Face Velocity
3. Electric heat performance is not within the scope of ARI Standard 430
certification.
4. All ratings shown are at 60 Hz. To obtain kW ratings at 50 Hz when voltage
does not change, multiply the 60 Hz rating by 0.833. For example, a 6-step
heater in a size 32 unit has a rating of 119 kW at 60 Hz. To obtain the
50 Hz rating:
119 x 0.833 = 99 kW at 50 Hz
If the voltage also varies from that shown in the table, use the formula in the
following example to arrive at the correct rating at the new voltage before
multiplying by 0.833:
Given: 2
V
2
()
kW
2
=kW
1
V
1
Where kW
1
= 60 Hz rating
kW
2
= 50 Hz rating
V
1
= 60 Hz voltage
V
2
= 50 Hz voltage
Example: 2
450
kW
2
=119
()
480
kW
2
= 105
105 x 0.833 = 87 kW at 450 v, 50 Hz
