Carrier VECTOR 1550 Series - Low Fuel Shutdown

62-61753-21
7-14
Alarm
NO.
Steps
ALARM / CAUSE
CORRECTIVE ACTION
19 LOW FUEL SHUTDOWN
This is an optional alarm. This alarm will not occur unless a fuel level sensor is present and configured ON
and a fuel tank size has be selected.
 TRIGGER ON:
"Check Fuel Sensor" alarm not active (if so, refer to alarm 126 first) and:
Fuel level is 10% or less for more than 1 minute when the unit is operating in diesel Mode
 UNIT CONTROL: Engine operation: alarm only or (if configured for shutdown) shutdown
and alarm.
Standby operation: this alarm will not activate in standby operation.
 RESET CONDITION: Auto reset when fuel level is above 12% for more than 1 minute, or alarm may
be manually reset via keypad or by turning the unit off, then back on again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, the active
alarm should clear itself (refer to reset condition above). Operate the unit through the appropriate modes to see if
any active alarm occurs. Continue with the steps below as necessary.
1
Check For Low Fuel Level Warning Alarm
a. Check for alarm 1.
Must be cleared.
2
Check For Low Fuel Level
a. Check fuel level in tank.
Add fuel as needed to the fuel tank.
