Table 3-1. Unit Data
* Displays information or setting entered in the microprocessor Configurations
+ May or may not be displayed depending on Parameter/Configuration settings
DATA
DEFINITION
SUCTION PRESSURE
Compressor suction pressure
DISCHARGE PRESSURE
Compressor discharge pressure
EVAPORATOR PRESSURE
Leaving evaporator pressure
ENGINE COOLANT TEMP
Engine coolant temperature
RETURN AIR TEMP
Return (air entering evaporator) air temperature
SUPPLY AIR TEMP
Supply (air leaving evaporator) air temperature
DELTA-T
Return air temperature minus supply air temperature
AMBIENT AIR TEMP
Ambient (air entering condenser) air temperature
DEFROST TERM TEMP
Defrost termination temperature
SUCTION LINE TEMP
Suction line temperature at the compressor
EVAP OUTLET TEMP
Suction line temperature at the evaporator outlet
COMPRESSOR DIS-
CHARGE TEMP
Compressor discharge temperature
BATTERY
Battery voltage
CURRENT DRAW (DC)
Battery charging or discharging amps.
ENGINE RPM
Engine revolutions per minute
UNIT AC CURRENT #1
High voltage current draw on circuit #1.
UNIT AC CURRENT #2
High voltage current draw on circuit #2.
SUCTION MOD VALVE
CSMV % open or "Closing"
EXPANSION VALVE
EVXV % open or "Closing"
START MODE
AUTO if the engine will start automatically
MANUAL if the engine must be started manually
SOFTWARE REVISION
Revision of the software that is operating the microprocessor
DISPLAY SOFTWARE REV
Revision of the software that is operating the display
CONTROL SERIAL #
Serial Number of the microprocessor
*
TRAILER ID #
ID (as Configured by the user)
*
UNIT SERIAL #
Unit serial number
*
UNIT MODEL #
Unit model number (as Configured by the user)
*
DATALOGGER
Displays the current Date and Time that the Data Recorder is using. This may
be different than local time, depending on the Time Zone and Daylight Savings
Time selections made when the Data Recorder was configured.
+
FUEL LEVEL
This is only displayed when the sensor is configured ON.
% of fuel in tank.
+
INSTALLED OPTIONS
This is only displayed when one or more options is configured ON.
Lists installed options.
+
HOURS TO ENGINE
MAINTENANCE
This is only displayed when the meter is configured ON.
Number of engine hours until the next programmed engine maintenance.
+
HOURS TO S/B MOTOR
MAINTENANCE
This is only displayed when the meter is configured ON.
Number of hours until the next programmed electric standby motor mainte-
nance.
+
HOURS TO UNIT MAINTE-
NANCE
This is only displayed when the meter is configured ON. Number of switch-on
hours until the next programmed general unit maintenance.
+
TIME LEFT TO PM (1-5)
This is only displayed when one or more of the meters is configured ON.
Number of hours until the next programmed maintenance. (May display user
programmed identification.)
