Carrier VECTOR 1550 Series User Manual

62-61753-21
7-52
Alarm
NO.
Steps
ALARM / CAUSE
CORRECTIVE ACTION
95 CHECK CDCON RELAY COIL
 TRIGGER-ON: Condenser Contactor Coil (CDCON) current is excessive
 UNIT CONTROL: Engine and standby operation: alarm only.
 RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit
off, then back on again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, the active
alarm should clear itself (refer to reset condition above). Operate the unit through the appropriate modes to see if
any active alarm occurs. Continue with the steps below as necessary.
1
Check CDCON
a. Inspect contactor coil and termi-
nals.
No damage to coil.
No damaged or corroded pins.
b. Check contactor coil resistance.
Refer to Section 2.12. Cannot be opened (infinite
ohms), shorted (Zero Ohms) or shorted to ground.
2
Check CDCON Current Draw
a. Use Component Test Mode to test
actual current draw of the coil. (Re-
fer to Section 5.1.2.)
Component FET or board LED (refer to Table 5-1)
must be illuminated.
View current draw in Data List.
Refer to Section 2.12 for normal current values.
3
Check CDCON Wiring
a. Inspect harness & control box
connector pins & terminals. (See
wiring schematic Section 10.)
No physical damage to harness.
No damaged or corroded pins.
96 CHECK GENCONR RELAY COIL
 TRIGGER-ON: Generator Contactor Relay coil (GENCONR) current is excessive
 UNIT CONTROL: Engine and standby operation: alarm only.
 RESET CONDITION: Auto Reset or alarm may be manually reset via keypad or by turning the unit
off, then back on again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, the active
alarm should clear itself (refer to reset condition above). Operate the unit through the appropriate modes to see if
any active alarm occurs. Continue with the steps below as necessary.
1
Check GENCONR
a. Inspect relay coil and terminals.
No damage to coil.
No damaged or corroded pins.
b. Check contactor coil resistance.
Refer to Section 2.12. Cannot be opened (infinite
ohms), shorted (Zero Ohms) or shorted to ground.
2
Check GENCONR Current Draw
a. Use Component Test Mode to test
actual current draw of the coil. (Re-
fer to Section 5.1.2.)
Component FET or board LED (refer to Table 5-1)
must be illuminated.
View current draw in Data List.
Refer to Section 2.12 for normal current values.
3
Check GENCONR Wiring
a. Inspect harness & control box
connector pins & terminals. (See
wiring schematic Section 10.)
No physical damage to harness.
No damaged or corroded pins.
