Case IH AFS Pro 700 - Offset settings for GPS

3-SETUP
“ForwardOffset,”“RightOffset,”and
“HeightOffset”
Whenamodel-speciclocationisselectedinthe“GPS
Location”window,defaultvaluespopulatethe“Forward
Offset”and“RightOffset”windows.Thewindowsare
dimmedandnoteditable.Thesevaluesareaccuratefor
thefactory-installedoreld-installedlocationoftheGPS
receiverwiththestandardmountingbracket.The“Height
Offset”windowdisplaysadefaultvaluethatisbasedon
avehicleequippedwithstandardtiresThiswindowised-
itable.Whenthe“Autoguidance”applicationispresent,
measuretheheightoffsetandadjustthevalueforaccu-
racy.Thevalueisusedforrollcorrectiontokeeptheve-
hiclealignedtotheswath.
When“Custom”isselectedinthe“GPSLocation”win-
dow,nodefaultvaluespopulatethe“ForwardOffset,”
“RightOffset,”or“HeightOffset”windows.Usethis
selectionwhentheGPSreceiverisnotmountedatthe
recommendedfactory-installedoreld-installedlocation,
orwhenacustombracketisinuse.Youmustmeasure
theforwardoffsetandrightoffsetandentereachvalue
intotheappropriatewindow.
RAIL14DSP1511BA8
Offsetvalues,whichdescribethedistancebetweenthe
GPSreceiverandtheGPSreferencepoint,arerequired
toachievemoreaccurateswathalignment,productappli-
cation,anddatamapping.Thedistancesaredescribed
inathreedimensionalplane.
TheGPSreceiverlocationisitsphysicallocationonthe
vehicle.Measurefromthebottomcenterofthereceiver.
RCIL11DSP302BBG9
TheGPSreferencepointvariesbyvehicle:
•
Frontsteertractors:thegroundbelowthecenterofthe
rearaxle
RAIL12DSP1510BA10
3-39
