3-SETUP
Swathmap
Theswathmapisasingle-layermapthatshowsswath
alignment(overlapandskip)andcanbeusedtoalignthe
vehicletothenextswath.
Mapsizes
Twodifferentswathmapwindows–“SwathMap1x4”and
“SwathMap2x5”–areavailableforthe“Run”screens.
Thewindowsdifferinsize,butnotinfunction.Therst
numberofthemaplabelindicatesthenumberofcolumns
usedonthe“Run”screens,andthesecondnumberindi-
catesthenumberofrows.
Somesoftwareallowstheoperatorstoplacethe“Swath
Map1x4”windowintheleft-handarea.Whenthe“Swath
Map1x4”windowisintheleft-handareaandona“Run”
screen,theleft-handareahaspriority.Whenthe“Run”
screenisviewed,the“SwathMap1x4”windowonlydis-
playsintheleft-handarea.
Whenthe“SwathMap1x4”windowisintheleft-hand
area,andthe“SwathMap2x5”windowisona“Run”
screen,the“Run”screenhaspriority.Whenthe“Run”
screenwiththelargermapisviewed,themaponlydis-
playsonthe“Run”screen.
“SwathMap1x4”example
RCIL11DSP030BBG1
“SwathMap2x5”example
RCIL11DSP031BBG2
