Case IH AFS Pro 700 - Swath map vehicle representation

3-SETUP
Vehicle
Agenericsymbolforthevehicletype–tractor,combine,
sprayer,etc–representsthevehicleintheswathmap.
Themapalwaysoffersazoomed-inviewofthecurrent
positionofthevehicleinrelationtothetwoswathson
eithersideofthevehicle.
RCIL11DSP032BBG3
Vehiclepositionontheswathmapisxedinthecenter
ofthemapwindow.Theeldandswathpatternrotate
aroundthevehiclewhenthevehiclechangesheading.
Thecompassintheupperleft-handcorneroftheswath
maprotatestoindicatethecurrentheadingofthevehicle.
RCIL11DSP033BBG4
The“SwathMap”windowisparticularlybenecialfor
aligningtothecorrectswathaftertheendofrowturnor
whenworkingaspiralorcircularpattern,especiallywhen
workingatnight.
RCIL11DSP034BBG5
3-163
