Case IH AFS Pro 700 - Map contents on swath map

3-SETUP
Mapcontents
Ifthevehicleisworking,theswathmapdisplaystheswath
widthforthevehicle(withitsimplementorheader)asa
greenareaoutlinedinblackasthevehiclemoves.Ifthe
vehicleisnotworking,noswathinformationismappedas
thevehiclemoves.
NOTE:Thecolorusedforcoveragehasnosignicance:
itdoesnotrepresentalevelofyield,application,orper-
formanceresults.
RAIL12DSP1002BA11
Ifarecordedswathisselectedfortheeld,aredline
representsthecurrentswath,andbluelinesrepresentthe
swathsoneitherside.Therecordedswathalsodisplays
ifitisinthecurrentviewoftheeld.
Theautoguidanceswathpatternisalwaysoverlaidonthe
workingswathswhenthe“Autoguidance”applicationis
present.
RCIL11DSP039BBG12
Theswathmapalsodisplaysanyeldmarks,boundaries,
andobstaclesthatarepresentinthecurrentviewofthe
eld.Thedisplayofmarks,boundaries,andobstacles
cannotbetoggledoffbyanyoperatorcontrolontheswath
map.
RAIL12DSP1003BA13
3-166
