Case IH AFS Pro 700 - Printer connection ports

5-"PRINTER"APPLICATION
Thetypesofportsthatareavailable–parallel,RS-232,
USB–andcablesthatareavailableforconnectinga
printertothedisplaywillvarywiththeprinter.
A9-pin(DB9)RS-232femaleconnectorisrequiredto
connecttheprintertothedisplayatthedisplayport.The
standardoroptionalcablesfortheprintermayormaynot
supportthisconnector.Acquireanyadaptersneeded–
a25-pinto9-pinRS-232,aUSBto9-pinRS-232,etc.–
fromalocalelectronicssupplier.
RCPH11DSP027BBG4
5-6
