6-VIRTUALTERMINAL(VT)ORUNIVERSALTERMINAL(UT)
“VTRAMMemory”
Placementlabel:VTRAMMem.
Placementlocation:“Run”screensorleft-handarea
AbargraphvisuallyrepresentstheuseofRandomAc-
cessMemory(RAM)byallactiveimplementortoolappli-
cations.
RAIL14DSP1403BA7
“VTUpload”
Placementlabel:VTUpload
Placementlocation:“Run”screensorleft-handarea
Abargraphvisuallyrepresentsprogressastheobject
poolforanimplementortoolapplicationisuploadedto
thedisplay.
RAIL14DSP1404BA8
