Case CX60C - Rearward Controls; Battery Disconnect Switch

3-CONTROLSANDINSTRUMENTS
Rearwardcontrols
Batterydisconnectswitch
Thebatterydisconnectswitchislocatedinthecab,behind
theoperator’sseat.
Thebatterydisconnectswitchallowstocutoffanypower
supplyintheelectricalsystemofthemachine.
NOTE:whentheswitchisturnedtoOFFposition,allelec-
tricalcircuitsarecutoffandthestationsstoredonthera-
diopresetsandthetimesetfortheclockwillbecleared.
SMIL16MEX1061AA1
Placethebatterydisconnectswitchinthe(I)positiondur-
ingnormaloperation.
Placethebatterydisconnectswitchinthe(O)position
onlyduringthefollowingoperations:
1.Batteryremoval.
2.Electricalsystemconnectorremoval.
3.Electricalsystemservice.
4.Long-termstorage.
5.Asrequiredforinspectionsandrepairs.
6.Welding
NOTICE:neverturnthebatterydisconnectswitchto(O)
positionwiththeenginerunning.Thiscoulddamagethe
electricalsystem.
NOTICE:neverturnthebatterydisconnectswitchto(O)
positionwithin3minafterthestarterkeyisturnedoff.The
machinecontrolsystemandtheenginecontrolsystemwill
bedamaged.
SMIL16MEX0410AA2
