3-CONTROLSANDINSTRUMENTS

3-CONTROLSANDINSTRUMENTS###_3_###

Accesstooperator'splatform

Doorandsteps

Cabdoor

CAUTION

Pinchhazard!

Becarefulnottogetyourhand,clothes,etc.

caughtinthedoorwhenclosingit.

Failuretocomplycouldresultinminoror

moderateinjury.

C0046A

Toopenthedoorfromoutsidethecab,usethehandle(1)

showninFigure1.

Toopenthedoorfrominsidethecab,usethehandle(2)

showninFigure2.

SMIL16MEX0698BB1

SMIL16MEX0578AA2

3-1
