3-CONTROLSANDINSTRUMENTS

Enginespeedcontrol

Theenginespeedcontrolknob(1)isusedtoincreaseor

decreasetherotationspeedofengine(RPM).

•

Turntheleverclockwise(A)toincreaseengineRPM.

•

Turnthelevercounterclockwise(B)todecreaseengine

RPM.

NOTE:whenstoptheengine,turntheenginespeedcon-

trollevercompletelycounterclockwise(B)andthenturn

thestarterkeyOFF .

SMIL16MEX3169AA1

3-26
