Case CX60C - Cab Tilting

3-CONTROLSANDINSTRUMENTS
Cabtilting
WARNING
Crushinghazard!
Whenyoutiltthecab,youmuststrictlyadheretotheinstructionsinthismanual.Keepallunautho-
rizedpersonnelclearofthearea.Donotoperateanycontrolswhenyouperformserviceunderthe
tiltedcab.
Failuretocomplycouldresultindeathorseriousinjury.
W1463A
NOTICE:thecabtiltingoperationmustbecarefullyperformedbyskilledserviceoperators.
NOTE:bytiltingthecab,serviceofhydraulicandelectricsystemsuchashydrauliccomponents,hydraulicpipings,
electriccomponents,andelectricwiringscanbeeasilyperformed.
Forwardtilting
1.Parkthemachineonaat,levelground,lowerthe
attachmenttothegroundandstoptheengine.
2.Lowertheoperator’sseatandmoveforwarditandthe
consolebox.
SMIL16MEX1358AA1
3.Removethetwopanelslocatedbehindtheoperator’s
seat.
4.Removethetwocabmountingnuts(1),thetwoplain
washers(2),thetworeboundwashers(3),thebolt(4),
andthepipe(5).
SMIL17MEX2690AB2
5.Removethecoverofthescrew(6)locatedonthefront
sideoftheupperstructure.
6.Screwthebolt(6)toraisethecab.
NOTE:themaximumtiltingangleis28°.
NOTE:operatethebolt(6)onlybyhandtools.
Tighteningtorque:lessthan294N·m(216.8lbft).
SMIL16MEX1109AA3
3-76
