Case CX60C - Air Conditioner Filters

6-MAINTENANCE
Airconditionerlters
CAUTION
Flyingdebris!
Compressedaircanpropeldirt,rust,etc.intotheair.Weareyeandfaceprotectionwhenusingcom-
pressedair.
Failuretocomplycouldresultinminorormoderateinjury.
C0049A
Cleantheaircirculationlterevery250h
Cleantherecirculationlterwhennecessary
Recirculationlter
1.Removetheoormat.
2.Usethelever(1)tomoveforwardtheoperator’sseat
andtheconsolebox.
SMIL16MEX1123AB1
3.Removethetwowingnuts(2)andtheonelocatedon
thebackoftheoperator’sseat.
4.Removethetwoscrews(3),theplate(4),andthepro-
tectionpanel(5).
SMIL16MEX1103AB2
5.Removethetworecirculationlters(6)andreplace
themwithnewlters.
SMIL16MEX1115AA3
6-45
