Case CX60C - Dimensions and Working Range

8-SPECIFICATIONS
Dimensions
SMIL16MEX1411FB1
(A)Overalllength5600mm(220.5in)
(B)Overallwidth,with380mm(15.0in)shoe1980mm(78.0in)
(C)Overallheight2550mm(100.4in)
(D)Superstructurewidth1950mm(76.8in)
(E)Overallheightofcab2550mm(100.4in)
(F)Groundclearanceofcounterweight660mm(26.0in)
(G)Enginecoverheight1670mm(65.7in)
(H)Minimumgroundclearance380mm(15.0in)
(I)Rear-enddistance1080mm(42.5in)
(I’)Rear-endswingradius1080mm(42.5in)
(J)Distancebetweentumblers1990mm(78.3in)
(K)Undercarriagelength2530mm(99.6in)
(L)Undercarriagewidth1980mm(78.0in)
(M)Trackgauge1600mm(63.0in)
(N)Trackshoewidth,standard380mm(15.0in)
(O)Heightofblade350mm(13.8in)
(P)Groundclearanceofbladeup200mm(7.9in)
(Q)Depthofbladedown700mm(27.6in)
Boomlength:2.9m(114.173in)
Armlength:1.48m(58.268in)
Withboomswingsystem
