Case CX60C - Fuel Filter Water Separator

6-MAINTENANCE
Fuellterwaterseparator
Drainwaterandsedimentfromthefuellterwaterseparatorevery10horeveryday.
Cleanthelterelementofthefuellterwaterseparatorevery50horeveryweek.
Replacethelterelementofthefuellterseparatorevery500h
Drainwater
1.Opentheenginehoodtoaccesstothefuellterwater
separatorandplaceacontainerwithanappropriate
capacityunderthefuellterwaterseparator(1).
SMIL16MEX1373AA1
2.Rotateclockwisethefuelcock(2)locatedonthefuel
lterwaterseparator(1)toclosethefuelow.
3.Loosenthedrainplug(3)locatedatthebottomofthe
fuellterwaterseparator.
4.Drainthewatercollectedinside.
5.Tightenthedrainplug(3)to1–2N·m(0.7–1.5lbft)
6.Openthefuelcock(2).
7.Primethefuelsystem.
8.Checkforleaks.
SMIL16MEX0600AB2
Primingthefuelsystem
1.TurnthestarterswitchtoONpositionfor10–15s.The
electricfuelpumpprimethefuelsystem.
NOTE:neverusethestartermotortocranktheenginein
ordertoprimethefuelsystem.Thismaycausethestarter
motortooverheatanddamagethecoils,thepinionand/or
theringgear.
SMIL16MEX0507AA3
