Case CX60C - When Necessary; Bulb Replacement

To Next Page

To Previous Page

6-MAINTENANCE

Whennecessary

Bulbreplacement

Lightingintheoperatorcompartment

1.Useaatscrewdrivertoremovetheprotectiveglassof

theceilinglightinordertoaccessthebulb(1).

SMIL16MEX1117AA1

2.Removethebulbandinstallanewoneofthesame

wattageintheceilinglight.

3.Puttheprotectiveglassontheceilinglightandpushit

tolock.

SMIL16MEX0934AA2

6-67
