3-CONTROLSANDINSTRUMENTS
Right-handsidecontrols
Right-handsidecontrols
SMIL16MEX1048FA1
(1)Beveragecanholder
(2)Starterswitch
(3)Instrumentcluster(refertopage3-27)
(4)Push-buttonpanel
(5)Ashtray
(6)Remotecontroller(refertopage3-53)
(7)Switchpanel
(8)12Vsocket
(9)USB/Auxsocket(hands-freedevice,refertopage
3-53)
(10)Dozerbladecontrollever(refertopage3-58)
(11)Cigarettelighterand12Vpowersupplysocket:the
deviceisactivewiththestarterkeyinONposition,or
whiletheengineisrunning.
Tooperatethecigarettelighter,pushitdowntoengage
itsheatingposition.
NOTICE:ifyoucontinuouslypushinthecigarettelighter,
youcancauseseriousdamagetothedeviceandthema-
chineelectricalsystem.
NOTICE:connectonly12V,120Wdevicestothesocket.
Connectingdevicesfunctioningatdifferentvoltagecan
causedamagestothedeviceitselfandtotheelectrical
system.
(12)Enginespeedknob
(13)Right–handcontrollever(referto3-6)
(14)RadioandUSBplayer(refertopage3-61).
3-21
