Case CX60C - Page 76

3-CONTROLSANDINSTRUMENTS
Starterswitch
Thestarterswitchhasthreepositions:
(1)OFF:engineshut–down.
(2)ON:contact,allthesystemsofthemachineoperate.
Thebuzzersoundsfor1s.
NOTICE:ifthisalarmdoesnotsound,theelectriccir-
cuitisabnormal.ContacttheCASECONSTRUCTION
dealerforinspectionandmaintenance.
(3)START:engineignition.
NOTE:thestarterkeyisalsousedtolockthecabdoor,
theenginehood,andthestoragecompartment.
SMIL16MEX0507AA2
Illuminationpush-button
Pressthepush–button(A)toturnontheillumination
lightsof:
airconditionerandheatercontroller;
radioandUSBplayer;
USBsocket,DPFswitch,enginespeedknob,andcigar
lighter.
Pressagainthepush–button(A)toturnoffthesameillu-
minationlights.
SMIL16MEX0506AA3
Worklightpush–button
Pressthepush–button(B)toturnontheworklightand
thepilotlightonthepanel.
Pressagainthepush–button(B)toturnofftheworklight
andthepilotlightonthepanel.
SMIL16MEX0506AA4
Travelalarmpush–button
Thetravelalarmpush–button(C),whenpressed,acti-
vatesabuzzertoalarmsurroundingthemachinewhen
themachinetravelsforwardandbackward.
SMIL16MEX0506AA5
3-22
