6-MAINTENANCE

Greasepoints(Boomswingcylinder)

Greasetheboomswingcylinderevery250h(After50hofoperationinrun-inperiod).

Lubricant:CASEAKCELAMOLYGREASE

Boomswingcylinder:onegreasetting

SMIL16MEX1424AA1

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL16MEX1377AA2

6-39
