Case CX60C - Hydraulic Oil Level

6-MAINTENANCE
Hydraulicoillevel
WARNING
Burnhazard!
Beforeperforminganyserviceonthehydraulicsystem,youmustallowittocool.Hydraulicuid
temperatureshouldnotexceed40°C(104°F).
Failuretocomplycouldresultindeathorseriousinjury.
W0241A
Checkthehydraulicoillevelevery10horeveryday
Fluid:CASEAKCELAHYDRAULICLL46
1.Parkthemachineonaatandlevelplace,andarrange
theattachmentasshowninthegure.Stoptheengine,
andremovethestarterkey.
SMIL16MEX1358AA1
2.Opentheenginehoodandthenthereardoortoaccess
thelevelgaugeofthehydraulicoiltank.
Theoillevelisnormalifitisbetweenthelinesofthe
levelgauge(1).
3.Ifthehydraulicoillevelisnotinthecorrectrangepro-
ceedasfollows:
•
Releaseallpressureinthehydraulictank.Referto
page6-12.
•
Cleanthecap(2)andtheareaaroundthecap.
•
Loosenthecap(2)andrelievethepressureinthe
tankbypushingthetopoftheairbreather.
•
Removethebreather(3)onthetopofthehydraulic
oiltankandlltheoiltothespeciedlevel.
•
Installthebreather(3).Tightenthebreather(3)to
11.3–16.9N·m(8.3–12.5lbft)
•
Tightenthecap(2).
NOTICE:makesurethatnocontaminant(water,sandetc.)
entersthereservoirduringlling.
SMIL16MEX1376AB2
4.Starttheengineafterllingandoperatetheworkequip-
mentseveraltimes.
5.Checktheoillevelafterenginestops.Closetherear
door.
6-26
