6-MAINTENANCE

4.Operatethetravelleversfromfronttorearadozen

timesapproximately.

SMIL16MEX1090BB3

5.Opentherefuelingdoorlocatedonthetopoftherear

doortoaccessthehydraulicoiltankbreather.

6.Loosenthecap(1)ofthehydraulicoiltankandpush

thetopoftheairbreather(2)torelievethepressure.

NOTE:thisproceduredoesnotcompletelyrelease

thepressure,sowhenoperatethehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL16MEX1096AB4

SMIL16MEX1420AB5

6-13
