6-MAINTENANCE

Ifthemachineisequippedwithsecondauxiliaryhydraulic

circuit(optional)proceedasfollows:

9.Slidetheleft-handproportionalswitchtoleft-handand

totheright-handthreetimesapproximatelytorelease

thepressure.

NOTE:thisproceduredoesnotcompletelyrelease

thepressure,sowhenoperatethehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL16MEX1498BA11

6-16
