6-MAINTENANCE
Startingtheenginewithboostercable
WARNING
Improperoperationorserviceofthismachinecanresultinanaccident.
Anerrorconnectingauxiliarystartingcablesorshort-circuitingbatteryterminalscancauseanacci-
dent.Connectauxiliarystartingcablesasinstructedinthismanual.
Failuretocomplycouldresultindeathorseriousinjury.
W0263A
Connectionofboostercable
Makesurethattheboosterbatteryvoltagecorresponds
tothevoltagesystemofthemachine.
MakesurethatthestarterkeyisinOFFpositionand
thesafetylockleverinLOCKposition.
Makesuretousesupplycablesofappropriatedimen-
sions.
Makesurethatthestarterkeyofthemachinewiththe
chargedbatteryisinOFFposition.
1.Connecttheredterminals(R)ofboostercableto
thebattery(+)terminalsbetweenexhaustedbat-
terypositiveterminal(1)andnewbatterypositive
terminal(2).
2.Connecttheblackterminal(B)oftheboosterca-
bletothebattery(-)terminalsbetweennewbattery
negativeterminal(3)andchassis(4)ofthema-
chinewiththeexhaustedbattery..
3.Connectionorder:(1),(2),(3),(4)
SMIL16MEX0459AB7
Startingtheengineofthemachine
1.Starttheengineofthemachinewiththecharged
batteryandkeepittorunathighRPM.
2.Starttheengineofthemachinewiththeexhausted
battery
3.Iftheenginedoesnotstart,restartaftertwomin-
utes.
Disconnectionofboostercable
1.Disconnectionorder:(4),(3),(2),(1)
2.Removetheblackboostercable(B).
3.Removetheredboostercable(R).
4.RuntheengineathighRPM.
