9-ACCESSORIES

Donotoperatethebreakertothesideofthemachine.

Themachinemaybecomeunstableandundercarriage

componentslifemaybereduced.

SMIL16MEX1406AA28

Operatetheexcavatorcarefullytoavoidhittingtheboom

withthehydraulicbreaker.

SMIL16MEX1407AA29

Donotoperatethebreakerwhilestriking.Thiscancause

damagetotheworkingdeviceandtotheswingsystem.

SMIL16MEX0467AA30

Donotoperatethehydraulicbreakercontinuouslylonger

than60s.Excessivechiselwearwillresult.Ifanobject

couldnotbebrokenwithin60s,applychiseltootherlo-

cations,lessthan60sforeachlocation.

NH020531
