Operationwiththehydraulicauger
Thehydraulicaugerisadouble-actinghydraulicattachment,andshallbeconnectedtotherstauxiliary(2-way)
hydrauliccircuit.
Therefore,tooperatewithahydraulicaugerthemachineshallbeequippedwiththerstauxiliary(2-way)hydraulic
circuit.
Aftermakingsurereadandunderstandtheinstallation
proceduredescribedintheOperator’smanualofthe
attachmentproceedasfollows:
1.Makesurethatthemachineandtheattachmenttobe
installedareonatandlevelground.
2.Operatethecontrolsofboom,armandbucketinorder
toinstallthebitwithitsrelativecradleandpowerhead
unitdrivetothebucketlinkageatthetopofthearm.
3.Stoptheengine.Releasepressureinsidetherstaux-
iliary(2-way)hydrauliccircuitasinstructedin6-12.
4.Installtheconnectinghosesbetweentheattachment
andtheendttingsonthebracketassemblylocated
ontheleft-handsideofthearm.
5.Checkthexingclampsforlooseness,andthetubes
andhosesttingsforleakages.
6.Useasuitablebeltwitheyebolt(A)tosecurethelink
rodonthetopofthearmtoavoidunappropriatedmov-
ingandtappingonthetopofthearm.
SMIL17MEX2805BA36
7.Starttheengine.Operatethecontrolsofboom,arm
andbucketinordertopositionaugertothepositionfor
thehole.
