Case CX60C - Page 307

9-ACCESSORIES
2.Lifttheredcover(A)toactivatethehydraulicquick
couplingswitch(B)todisengagecouplersystemfor
2s,thenlowertheredcover(A)toreleasethequick
couplingswitch(B).
NOTE:todisengagetheattachmentisnecessary
keeppressedthehydraulicquickcouplingactivation
switch(B).
3.Holdthebucketcurlleverforapproximatelyfor3–5s
toallowthehooktofullyretractplacecouplerinthe
fullycurledposition.
4.Releasethequickcouplingactivationswitch(B).
WARNING
Impactandcrushinghazard!
Neveruseladdersorothermeanstodisen-
gagetheattachment.
Keepclearoftheattachmentduringthedisen-
gagementprocedure.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1493A
SMIL18MEX0091BA12
5.Oncethejawisfullyretracted,lowertheattachment
togroundandslowlycurlthecouplerbacktorelease
therearattachmentpin.
SMIL17MEX2830AA13
6.Liftthedipperarmuntilthecouplerhasdisengaged
fromthefrontattachmentpin.Theattachmentisnow
safetydisengaged.
SMIL17MEX2831AA14
9-53
